WINKHAUS AV2 Auto Locking Lever Operated Latch & Deadbolt 20mm Radius - 2 Hook
- Winkhaus
- WINKH_0030
- In Stock
-
£194.36
- Exc. VAT: £161.97
Available Options
The automatic locking AV2 2 hook multipoint lock has a 20mm radius faceplate and is ideal for use on timber doors. The AV2 Autolock has the optional capability of becoming an electronic access controlled locking system. The lock is designed to accept a screw on 12v electronic motor which can then be controlled by means of industry standard multi option access control systems. When activated the two solid high tensile steel hooks and central latch are withdrawn thus forming the blueMatic AV2-E. The extreme versatility of the blueMatic AV2-E Electronic Locking system is achieved through its easy integration with all access control systems which subsequently leads to its suitability for many different applications.
WINKHAUS AV2 Auto Locking Lever Operated Latch & Deadbolt 20mm Radius - 2 Hook
Features
- 20mm Radius Faceplate
- Euro profile lock case
- Latch & Deadbolt
- Can be fitted with electronic motor
- Ideal for timber doors
Categories
- Architectural Hardware
- Door
- Full Units
- Winkhaus
- Multi Point Locks
Our WINKHAUS AV2 Auto Locking Lever Operated Latch & Deadbolt 20mm Radius - 2 Hook from Winkhaus is a quality tested product at a reasonably low price.
If you need any further information or are looking for an alternative size or similar item please contact us.
* Information above is accurate at the time of entry and may be subject to change at any time.
| Specifications & Variations | |
| Backset | 35mm, 55mm, 45mm |
| Barcodes | 5055120780023, 4026058101151, 5055120745824, 4026058101229, 4026058101182, 5055120745794 |
| Case Height | 186mm |
| Case Width | 63mm, 73mm |
| Centre Case | Latch & Deadbolt |
| Centres | 92mm |
| Faceplate Height | 1770mm |
| Faceplate Width | 20mm Radius |
| Handed | Left Hand, Right Hand |
| Length | 1.77m |
| Locking Point Hooks | 2 |
| Pack Quantity | 1 |
| Product References | L26602, L26601, L23476, L23475, L23474, L23473 |
| Spindle | Single |
